np 3153 sh 3~ 276

patented self cleaning semi-open channel impeller, ideal for pumping in most waste water applications. possible to be upgraded with guide-pin® for even better clogging resistance. modular based design with high adaptation grade.

technical specification

curves according to:

head [m]

36 34 32 30 28 26 24 22 20 18 16 14 12 10

8 6 4 2 0

water, pure [100%],4 °c,999.9 kg/m3,1.5692 mm2/s

57.4%

276 158mm

0 20 40 60 80 100 120 [m3/h]

curve: iso 9906

configuration

motor number

n3153.182 21-18-2fb-w 11kw

impeller diameter

158 mm

pump information

impeller diameter 158 mm

discharge diameter

80 mm

inlet diameter 150 mm

maximum operating speed 2895 rpm

number of blades 2

installation type
p - semi permanent, wet

discharge diameter

80 mm

materials

impeller
grey cast iron

project created by last update block created on 2/19/2020

np 3153 sh 3~ 276

technical specification

motor - general

motor number n3153.182 21-18-2fb-w 11kw

phases 3~

rated speed 2895 rpm

rated power 11 kw

frequency 50 hz

motor - technical

power factor - 1/1 load 0.94

power factor - 3/4 load

0.93

power factor - 1/2 load

0.89

rated voltage 380 v

motor efficiency - 1/1 load

89.5 %

motor efficiency - 3/4 load

91.2 %

motor efficiency - 1/2 load

92.1 %

insulation class h

total moment of inertia 0.0294 kg m2

starting current, direct starting 131 a

starting current, star-delta 43.7 a

number of poles

rated current

stator variant type of duty

s1

starts per hour max. 30
